Spiral mixer with removable bowl DIOSNA SPV 120 - 240
Spiral mixer with removable bowl, DIOSNA SPV 120, SPV 160, SPV 200, SPV 240
Advantages:
- Smooth surfaces, easy to clean
- Protect against dusting, cover for bowl
- Smooth surfaces and ground clearance for easy cleaning
- Standard pliers lock
- Compact design, also ideal for small and medium-sized bakeries
- Easy to operate with program memory in membrane keypad version CS03 or pushbutton control with digital time switches
- Two speeds
- Control: standard (D models): i-Timer, 2 alarm clocks, automatic speed shift
Options
- Control (A models): Data Memory CS03, 99 recipes/5 steps or computer control with PLC touch screen/40 recipes/40steps
- Temperature control by infrared temperature sensor or bowl scraping device with temperature sensor PT 100
- Pliers and console made of stainless steel
- M6 geared bowl
- Programmable logic controller with touch control panel
- Energy Control
- Rotation control
Spiralni mixers with removable bowl DIOSNA SPV
Technical data:
| SPV 120A | SPV 160A | SPV 200A | SPV 240A | |
| Dough capacity (max) | 120 kg | 160 kg | 200 kg | 240 kg |
| Flour capacity (max) | 75 kg | 100 kg | 1250 kg | 150 kg |
| Bowl volume | 180 L | 260 L | 300 L | 355 L |
| Tool power, standard | 4,0/8,0 kW | 11,0/18,5 kW | 11,0/18,5 kW | 11.0 /18,5 kW |
| Tool power, with frequency converter | – | 22,0 kW | 22,0 kW | 22,0 kW |
| Bowl power standard | 0,45 kW | 1,3 kW | 1,3 kW | 1,3 kW |
| Bowl power, with frequency converter | – | 1,5 kW | 1,5 kW | 1,5 kW |
| Fuse | 32 A | 63 A | 63 A | 63 A |
| Weight (Kneader without bowl) | 830 kg | 1.320 kg | 1.320 kg | 1.320 kg |
| Weight (bowl) | 170 kg | 195 kg | 215 kg | 230 kg |
| Dimension
Width Depth Height |
800 mm 1.400 mm 1.505 mm |
944 mm 1.497 mm 1.470 mm |
944 mm 1.532 mm 1.470 mm |
1.000 mm 1.582 mm 1.470 mm |
